diy battery holder
3.2V LiFePo4 32700 Battery 6500mAh DIY Nickel Sheet with Battery Holder Rechargeable Lithium Iron Phosphate Battery
|
3.2V LiFePo4 battery specifications |
|
|
Model: |
32700 |
|
Battery Type: |
Lifepo4 |
|
Rated power: |
6500mAh |
|
Standard Voltage: |
3.2v |
|
Battery Size: |
32x70mm |
|
Battery Weight: |
About 145 g |
|
Internal resistance: |
Less than 8 microns |
|
Life time: |
Over 2000 times, DOD at 80% |
|
Combination: |
Maybe 3s 4s 8s 10s 13s etc. |
|
Charger input voltage |
3.65 in / cell |
|
Input Charging Current |
3A |
|
Continuous Discharge Current |
30A |
|
Maximum discharge current |
6C |
|
Disconnect Voltage |
2.50 in / cell |
|
Charging temperature: |
0 ~ 45 degrees centigrade |
|
Discharge temperature: |
-20 ~ 60 degrees centigrade |
|
Storage temperature: |
-20 ~ 45 degrees Celsius |
|
Wide application: |
Electric car, electric bike, tricycle, scooter, golf cart, trolley, wheelchair, medical instrument, solar power system, solar panel, energy storage, power tools, power tools, tools, LED lighting, radio-controlled toys, inverter, household appliances and device area, etc. |
16PCS 3.2V 22Ah LifePO4 battery 46160 10C discharge DIY 12V 24V for energy storage car starter battery + battery holder
▲About EU tarife und steuern
1. EU mitglied staaten, duty-freies und zollabfertigung gebühren für waren über 150 euro (ohne fracht), DPD duty-freies tür-zu-tür service.
2. der preis angezeigt durch die EU mitglied staaten ist die mehrwertsteuer hinzugefügt durch die plattform durch standard, und die mehrwertsteuer wird automatisch abgezogen für aufträge größer als 150 euro (ohne fracht). Keine mehrwertsteuer und gewohnheiten gebühren sind aufgeladen.
[Product Specifications]
Rated capacity: 22Ah
Battery Type: Lithium Iron Phosphate
Nominal voltage: 3.2V
Nominal capacity: 22000mAh@0.5C
Battery internal resistance: ≤3.0mΩ (50%SOC)
Maximum charging voltage: 3.65V
Discharge cut-off voltage: 2.5V
Minimum discharge cut-off voltage: 2.0V
Maximum continuous discharge current: 110A (5C)
Maximum pulse discharge current: 220 (10C)
Fast charging method
Standard charging current: 11A
Quick Charge: 22A
Max charge: 44A
Cycle life: ≥2000cycles (80%EOL)
Battery weight: 570.0±10 g
Size: 160*46mm
Operating temperature
Working temperature (charging): 0-45℃
Operating temperature (discharge): -20–60℃
application:
Electric vehicles, model aircraft, power tools, golf carts, tourist vehicles, electric motorcycles, electric bicycles, laptop batteries, power tools, solar and wind energy systems, LED flashlights, power tools, mobile equipment, backup power, RVs, station wagons, UPS power...
Passenger cars and commercial plug-in hybrid electric vehicles (PHEVs)
Passenger and commercial battery electric vehicles (BEVs)
manifest:
3.2V 22Ah battery*16PCS
tighten
connecting copper
battery holder
New 1-4 Slots 18650 Battery Holder 18650 Battery Storage box With Wire Lead 18650 Power Bank Case 1X 2X 3X 4X DIY Storage Cases
Specification:
Brand new
Material: plastic
Color: black, as picture shows
For 18650 3.7V battery
Package included:
1 x battery holder (battery is not included)
New Plastic 18650 Battery Storage Box Case 1 2 3 4 Slot Way DIY Batteries Clip Holder Container With Wire Lead For 18650 Battery
New Plastic 18650 Battery Storage Box Case 1 2 3 4 Slot Way DIY Batteries Clip Holder Container With Wire Lead For 18650 Battery Drop shipping
Transition: 1cm=10mm=0.39inch
Dimension:
1X18650:75X20X18mm
2X18650: 75X40X18mm
3X18650: 75X60X18mm
4X18650: 75X80X198mm
Material: Plastic
Color: Black
Package include: 1 x Battery Holder(Battery is not include)
ABS 18650 Power Bank Cases 1X 2X 3X 4X 18650 DIY Battery Holder Storage Box Case 1 2 3 4 Slot Batteries Container With Hard Pin
ABS 18650 High quality DIY battery box 1X 2X 3X 4X 18650 Black Power Bank Cases 1 2 3 4 Slot Batteries Container With Hard Pin
Features:
100% brand new and high quality
New generic battery storage case box for easy power solutions.
It can hold standard 18650 sized batteries, either for disposable or rechargeable batteries, the hard pins are great for easily soldering and connecting.
Can hold 1/2/3/4 pieces 3.7V*N battery pack from single cells.
DIY extension, you can use this battery case with your own batteries to form a new power supply system.
Great items for keeping your rechargeable batteries organized and protected.
Ideal for electronics applications and DIY projects.
Specifications:
Material: ABS
Type: For 18650 Battery
Input Voltage: 3.7V
Color: Black
Quantity:1 Pc
Attentions:
1. Please allow tiny size deviations due to human measurement.
2. Please do not separate, maintain, or refit the product.
3. The wires are thin, and this product is only fit for small current load. DO NOT connect it to a load that will cause large current, stop using this product if the wires are very hot.
4. Please pay attention to your battery heat generation while using this product and do not charge inferior batteries.
Package includes:
1 x Battery Case
AA No.5 AAA No.7 series battery box tape line with switch DC head DIY battery holder 1 2 3 4 6 8
Plastic Power Bank DIY Battery Holder Storage Box Case for 1x18650 Battery Holder Cover Box connectors
A battery holder is one or more compartments or chambers for holding a battery. For dry cells, the holder must also make electrical contact with the battery terminals. For wet cells, cables are often connected to the battery terminals, as is found in automobiles or emergency lighting equipment. Where the battery is expected to last over the life of the product, no holder is necessary, and a tab welded to the battery terminals can be directly soldered to a printed circuit board. A good choice for you!
Features:
- High Quality Plastic Holder.
- Small size, easy to carry.
- 1pcs 18650 Battery Holder Case Leads 3.7V Clip Type for Soldering / Connecting.
- Takes 1 standard size 18650 batteries side by side to form a compact battery of 3.7V using alkaline batteries.
- Batteries Not Included.
Specifications:
1. Color: Black
2. Battery Type: 18650
3. Dimensions:
Battery Holder For 1x 18650: approx.7.6cmx2cm/3.0" x 0.8"
Battery Holder For 2x 18650: approx.7.6cmx3.9cm/3.0" x 1.5"
Battery Holder For 3x 18650: approx.7.6cmx5.9cm/3.0" x 2.3"
1pc Plastic Battery Holder Storage Box Case
6PCS 3.2V 22Ah LifePO4 battery 46160 10C discharge DIY 12V 24V for energy storage car starter battery + battery holder
6PCS 3.2V 22Ah LifePO4 battery 46160 10C discharge DIY 12V 24V for energy storage car starter battery + battery holder
[Product Specifications]
Rated capacity: 22Ah
Battery Type: Lithium Iron Phosphate
Nominal voltage: 3.2V
Nominal capacity: 22000mAh@0.5C
Battery internal resistance: ≤3.0mΩ (50%SOC)
Maximum charging voltage: 3.65V
Discharge cut-off voltage: 2.5V
Minimum discharge cut-off voltage: 2.0V
Maximum continuous discharge current: 110A (5C)
Maximum pulse discharge current: 220 (10C)
Fast charging method
Standard charging current: 11A
Quick Charge: 22A
Max charge: 44A
Cycle life: ≥2000cycles (80%EOL)
Battery weight: 570.0±10 g
Size: 160*46mm
Operating temperature
Working temperature (charging): 0-45℃
Operating temperature (discharge): -20–60℃
application:
Electric vehicles, model aircraft, power tools, golf carts, tourist vehicles, electric motorcycles, electric bicycles, laptop batteries, power tools, solar and wind energy systems, LED flashlights, power tools, mobile equipment, backup power, RVs, station wagons, UPS power...
Passenger cars and commercial plug-in hybrid electric vehicles (PHEVs)
Passenger and commercial battery electric vehicles (BEVs)
manifest:
3.2V 22Ah battery*6PCS
tighten
connecting copper
battery holder
Lifepo4 Battery 3.2v 25ah 1PCS Battery Pack High Current Large Capacity Car Cells Diy 24V Solar Energy Storage RV Golf Car
NEEXGENT Lifepo4 Battery Cell 3.2v 25ah Brand New Grade A Deep Cycle RV EV Boats Golf Cart Home Solar Storage System
Nominal Capacity(AH) | 25Ah |
Nominal Voltage(V) | 3.2V |
Standard Charge Current(A) | 0.5C |
Maximum charge current(A) | 1C |
Impedance(Ω) | 0.2mΩ |
Max. discharge current(A) | 2C |
Max.charge voltage(V) | 3.65V |
Discharge cut-off voltage(V) | 2.5V |
Charge working temp.(ºC) | 0~55ºC |
Discharge working temp.(ºC) | -20~55ºC |
Cycle life | 6000 Cycles |
1-2PCS 3.2V LiFePo4 32700 battery 6500mAh DIY nickel sheet with battery holder, rechargeable lithium iron phosphate battery
3.2V LiFePo4 battery specifications | |
Model: | 32700 |
Battery Type: | Lifepo4 |
Rated power: | 6500mAh |
Standard Voltage: | 3.2v |
Battery Size: | 32x70mm |
Battery Weight: | About 145 g |
Internal resistance: | Less than 8 microns |
Life time: | Over 2000 times, DOD at 80% |
Combination: | Maybe 3s 4s 8s 10s 13s etc. |
Charger input voltage | 3.65 in / cell |
Input Charging Current | 3A |
Continuous Discharge Current | 30A |
Maximum discharge current | 6C |
Disconnect Voltage | 2.50 in / cell |
Charging temperature: | 0 ~ 45 degrees centigrade |
Discharge temperature: | -20 ~ 60 degrees centigrade |
Storage temperature: | -20 ~ 45 degrees Celsius |
Wide application: | Electric car, electric bike, tricycle, scooter, golf cart, trolley, wheelchair, medical instrument, solar power system, solar panel, energy storage, power tools, power tools, tools, LED lighting, radio-controlled toys, inverter, household appliances and device area, etc. |
